Micro-Inverter, 1600W Grid Tie Inverter for MPPT 99.5% Efficiency, Wireless APP Monitoring for Solar Power Station 120/230 Volt AC(1600w)

Features:1.High accuracy: The 1600W solar inverter has built-in high- for precision instruments that can detect the working status of each component.2.Safe to use: the miniature inverter can control each component independently of each other, minimising potential safety risks and accidents.3.MAXIMUM OUTPUT PERFORMANCE: miniature Inverter Solar Grid-Tie Inverters can achieve maximum power point tracking to maximize overall power output.4.Wireless: you can remotely control and monitor via or a mobile app, which greatly improves overall efficiency.5.Easy installation: the miniature inverter can be installed directly behind the module or on a bracket to simplify user maintenance.Specification:Item Type: Solar Grid Tie miniature InverterModel: WVC-1600Material: Aluminum AlloyMaximum Input Power: 1600WPeak Current Tracking Voltage: 22-60VMinimum or Maximum Start Voltage: 22-55VMaximum DC Short Circuit: 30AMaximum Input Operating Current: 22-55A 7.2 A.Ambient temperature range:-40℃ to 60℃Water resistance: IP65Communication method: wireless mode Powertransmission mode: reverse transmission, load priority for peakpower: 1600WRated output power: 1600WRated output current: 120V: 5A 230V: 2.6ARated voltage range: 120V: AC 85-165 V. 230V: AC 185-265VRated Frequency Range: 47-52/57-62HzPower :>99%Maximum Output Efficiency: 120V: (Single) 230V:(Single Phase) Output Power: 120V 230V StaticMPPT Effect Degree: 99. 5%Maximum units per branch: 95% Power consumption at nightPackage Contents:1*1600W Inverter1*Instruction1*Fixing screw sleeve1*M25 male head1*2m cableUse:1. Use the screws supplied with the machine to install and attach the inverter to the holder of the photovoltaic module.2. Connect the DC connector of the photovoltaic module to the DC input terminal of the inverter.

• [POWERFUL 1600W OUTPUT WITH 99.5% MAXIMUM EFFICIENCY]: This micro-inverter delivers an impressive peak-power of 1600W with a rated output of 1600W, featuring advanced maximum power point tracking technology that achieves 99.5% MPPT effectiveness. The high-performance aluminum alloy construction with IP65 water resistance rating allows operation in ambient temperatures from -40℃ to 60℃, making it suitable for various weather conditions while maintaining stable power conversion rates above 99% to optimize your solar harvest throughout the day.
• [SMART WIRELESS MONITORING AND CONTROL SYSTEM]: Monitor and manage your solar power system remotely through mobile app connectivity, providing real-time data on power generation, system status, and performance metrics from anywhere at any time. This wireless communication feature eliminates the need for physical inspections and enables you to track energy production, identify issues quickly, and adjust settings conveniently, significantly enhancing the operational efficiency of your solar installation while giving you complete control over your renewable energy system.
• [SIMPLE INSTALLATION WITH VERSATILE MOUNTING OPTIONS]: The compact micro-inverter design allows for straightforward installation directly behind solar panels or on mounting brackets using the included fixing screw sleeve, M25 male connector, and 2-meter cable. The plug-and-play DC connectors from your photovoltaic modules connect seamlessly to the inverter's input terminals, eliminating complex wiring requirements. This user-friendly setup reduces installation time and simplifies ongoing maintenance tasks, making it accessible even for those with limited technical experience in solar systems.
• [INDEPENDENT COMPONENT CONTROL FOR ENHANCED SAFETY]: Equipped with sophisticated instruments for high-accuracy detection, this grid-tie inverter monitors the working status of each solar panel component independently, allowing individual control and optimization of every connected module. This intelligent architecture minimizes potential safety risks by isolating problems to individual components rather than affecting the entire system, while the reverse transmission mode with load priority ensures stable power delivery and protects your home electrical system from fluctuations and irregular power supply issues.
• [WIDE VOLTAGE COMPATIBILITY FOR FLEXIBLE APPLICATIONS]: Compatible with both 120V systems (AC 85-165V, 5A rated output) and 230V systems (AC 185-265V, 2.6A rated output), this inverter works with peak current tracking voltage of 22-60V and supports maximum DC short circuit protection up to 30A. The rated frequency range of 47-52Hz/57-62Hz accommodates different grid standards, while the maximum input power capacity of 1600W with operating current of 7.2A allows you to connect multiple solar panels efficiently for expanded power generation in residential or commercial applications.
